Fiber-to-the-Home Cable Production: Step-by-Step Manufacturing Process
Surprising fact: in excess of 70% of U.S. broadband rollouts now depend on fiber networks that need high-precision manufacturing to hit performance targets.
Shanghai Weiye OFC Equipment manages end-to-end SZ stranding line manufacturing, from choosing brand fibers like Fujikura or Corning SMF-28e to final test reports that guarantee full quality assurance.
Our drop designs suit aerial, ducted, and direct burial installation, with low-smoke zero-halogen (LSZH), PVC, and polyethylene (PE) jacket options and core counts from 1–4 cores. We supply single-mode OS1/OS2 and OM2–OM4 grades plus ITU-T G.652D and ITU-T G.657 variants, Pantone-matched sheath colors, and logo printing.
Automation and precision equipment keep line speed steady and keep repeatability high. Typical lead times run 4–5 days for orders under 100 km and seven to ten days under 500 km, with an min. order of 1 km and warranty for free replacement on quality issues.
Keep reading to learn how materials plus testing and support work together to reduce lifecycle cost and align the product to your network needs.
- Shanghai Weiye OFC Equipment offers full manufacturing with lab validation for United States projects.
- A range of jacket options and fiber grades support varied installation environments.
- Automated production lines provide stable quality and stable optical performance.
- Fast lead times, low MOQ, and recognized brand fibers keep procurement predictable.
- Comprehensive test reports and after-sales warranty support product reliability and documentation needs.
Expert FTTH manufacturing by Shanghai Weiye OFC Equipment
When deadlines and performance are critical, Shanghai Weiye OFC Equipment provides tailored drop solutions with complete test documentation.
As a focused supplier and manufacturer, Shanghai Weiye OFC Equipment pairs purpose-built equipment with stringent material control. We provide customized service and products for residential and MDU rollouts. Every order includes full QA coverage and full test reports.
Our lab runs high heat, salt-fog, and vibration testing to validate durability. Jacket options cover LSZH, PVC, and PE. Designs offer bow-type flat and figure-8/self-supporting styles and use brand fibers such as Fujikura and Corning SMF-28e.
- Controlled production lines and in-process checks for fully auditable shipments.
- Engineering support for specification reviews, trials, and volume ramp.
- Modern fixtures and calibration minimize variation so every cable matches operator specs.
FTTH cable production
At Shanghai Weiye OFC Equipment, manufacturing steps are built around network requirements, combining brand fiber choices with disciplined test flows.
Selecting Optical Fiber and Brands
We align Fiber coloring machine to minimum bend radius, loss, and deployment type. Options include OS1/OS2 and OM2–OM4 and G.652D and G.657.A1/A2 per ITU-T. Brand fibers such as Fujikura and Corning SMF-28e are available to meet procurement standards.
Integrating Strength Members
Strength members employ FRP (dielectric) or galvanized steel wire. FRP is preferred where non-conductivity is necessary. Steel wire provides tensile strength for long-span aerial runs and grounding needs.
Jacket Options and Control
Jacket options include LSZH for indoor flame safety, PVC for flexibility and ease of handling, and PE for outdoor UV and moisture resistance. Closed-loop control of temperature and capstan ratios stabilizes line speed and critical dimensions.
| Component | Dielectric FRP | Metallic Steel |
|---|---|---|
| Use case | Electrical isolation | Aerial spans, high tensile |
| Advantage | Lightweight, inert | High strength |
| Installation note | Simple terminations | Requires grounding |
Testing & Verification
Inline geometry/concentricity checks operate in-line. Final optical tests confirm loss and reflectance. Each order ships with a full test report and lab results from high-temperature, salt-spray, and vibration trials to qualify field handling and drop terminations.
Typical lead times are 4–5 days for < 100 km and under 500 km in 7–10 days. Material lot records and first-article approvals provide traceability and compliance for U.S. projects.
FTTH drop cable types and structures we manufacture
Shanghai Weiye OFC Equipment provides a compact portfolio of drop designs that suit both tight indoor routes and exposed aerial spans. Each option pairs tested materials with geometry tuned for field termination and consistent optical performance.
The flat bow-type drop keeps a small footprint for risers and conduit. It reduces bend loss for simple routing in hallways and MDUs.
Self-Supporting Aerial Designs
Self-supporting FTTH drop designs use a messenger element to handle tension. Choose FRP (dielectric) for non-conductive runs or steel messenger when bonding and higher tensile strength are required.
Core Layouts and Strength Members
We offer dielectric and metallic strength member configurations to meet safety/EMI requirements. Central loose-tube and flat unitube types balance crush resistance and Fiber draw tower for quick termination.
Jackets for Indoor/Outdoor
Jacket choices include LSZH for flame-retardant, low-smoke indoor use and PE for outdoor durability. Each family is validated for mechanical and optical quality before shipment.
| Type | Best use | Strength member | Sheath |
|---|---|---|---|
| Bow-type flat | Indoor risers and MDUs | Dielectric FRP | LSZH |
| Self-supporting | Aerial spans | FRP/Steel | PE |
| Central loose-tube | Higher fiber counts | FRP | LSZH/PE |
| Flat unitube | Low-count, easy strip | FRP/Steel | LSZH/PE |
Production Assets for Speed and Quality
Automation and sensor-driven feedback at Shanghai Weiye OFC Equipment cut manual handling and boost throughput for patch cord prep.
Our production line uses automated machines that cut and strip drop patch cords to raise throughput and cut labor variability.
The CLX-BPO2 auto-stripping machine uses PLC + photoelectric control. One cycle is about 1.5 seconds, giving real-world speeds near 20 terminal operations per minute.
Automated Cut/Strip for Drop Cords
The equipment strips LSZH and PVC jackets and trims FRP or steel strength members to precise reserved lengths. Cylinder-driven actuators deliver fast, repeatable motion and low downtime.
PLC & Photoelectric for Precision
PLC logic + photoelectric sensors deliver precise positioning and closed-loop control. Inline checks feed control charts so operators can correct trends before defects grow.
| Item | Capability | Result |
|---|---|---|
| CLX-BPO2 | Auto-strip, ~1.5 s cycle | ~20 terminals/minute throughput |
| Actuation | Pneumatic cylinders | High speed and reliability |
| Material handling | LSZH/PVC; FRP/steel | Accurate stubs, clean terminations |
| Control | PLC/photoelectric with in-line SPC | Stable quality, reduced rework |
- Auto scrap ejection and ergonomic loading maintain clean workcells.
- PCPs capture calibration intervals and critical parameters.
- Integrated assets and trained operators support FTTH volume targets without compromising accuracy.
CLX-BPO2 auto-stripping machine capabilities in our line
The CLX-BPO2 brings industrial-grade stripping and trimming to our line, cutting cycle time while keeping prep consistent.
Shanghai Weiye OFC Equipment deploys the CLX-BPO2 to increase throughput and standardize prep quality. The unit runs at an approximate cycle time of 1.5 seconds, yielding about 20 terminal preparations per minute in production.
PLC and photoelectric control enable precise detection and repeatable motion. That control helps keep strip lengths and reserved strength stubs within tight tolerances.
Throughput & Cycle Time
Typical operation speed is ~1.5 seconds per cycle. This translates to steady throughput under continuous line conditions.
Jacket Strip & Stub Lengths
The CLX-BPO2 handles LSZH/PVC with an adjustable strip length from 17.5 to 35.0 mm. Reserved strength member stubs are adjustable from 7.0–11.0 mm to fit common termination hardware.
Cutting FRP/Steel Members
The machine cleanly cuts FRP and steel wire strength elements while protecting adjacent fibers. Custom tooling are available for non-standard cross-sections to preserve precision.
- Auto-eject scrap and sensor start cut idle time.
- Small footprint (L40 × W18 × H18 cm), 110–220V, 50W, and 11 kg weight simplify cell integration.
- Cylinder-driven motion and PLC/photoelectric control boost reliability and reduce maintenance downtime.
| Spec | Value | Why it matters |
|---|---|---|
| Cycle time | ~1.5 s (~20/min) | Supports high-volume runs |
| Strip lengths (A) | 17.5 to 35.0 mm | Fits common connector processes |
| Reserved stub (B) | 7.0–11.0 mm | Supports termination strength |
| Power & size | 50W @ 110–220V; 40×18×18 cm | Simple integration |
Using this machine, Shanghai Weiye OFC Equipment standardizes terminal prep so field teams get drop parts install-ready. The CLX-BPO2 helps our production lines meet volume goals without sacrificing quality.
Custom Specs for Your FTTH System
Shanghai Weiye OFC Equipment configures each build to meet your network requirements and simplify field rollout. We combine focused options with predictable schedules so your teams receive ready-to-install products.
Choose 1 to 4 cores with SM or MM fiber. Options include OS1, OS2, and OM2–OM4 plus G.652D/G.657 variants to match your optics and connector plans.
We match sheath colors to Pantone codes for quick field identification and consistent asset tags.
Branding and Print Options
Select LSZH, PVC, or PE jackets to suit route and safety requirements. Custom print legends and logos support inventory and warranty tracking.
Lengths, Packaging & Special Builds
Standard reel lengths are 1 km, 2 km, and 4 km with custom reels and packaging to fit storage/handling. Choose flat bow-type or self-supporting and steel wire or FRP strength members to meet span and isolation needs.
| Option | Common choice | Benefit |
|---|---|---|
| Length | 1, 2, or 4 km | Less staging, easier reels |
| Jacket | LSZH / PE / PVC | Indoor/Outdoor fit |
| Structure | Bow-type / Self-supporting | Flexible routing/span |
As a supplier, Shanghai Weiye schedules runs to your plan and delivers documentation that lists final specifications for easy on-site QA.
Quality, Test, and Docs
Shanghai Weiye OFC Equipment builds checkpoints into production so every item has recorded acceptance data at ship.
Environmental and Mechanical Tests
Our lab runs elevated-temperature exposure, salt spray corrosion, and vibration tests to qualify materials/assemblies. These tests recreate field stresses for indoor/outdoor applications.
100% test reports for every cable
Every fiber optic cable includes a 100% test report that logs attenuation, return loss, and geometry where applicable. Final inspection gates prevent nonconforming shipments before they leave the factory.
Traceability & Compliance
Batch records tie test data to reels and serials so audits and claims are easy to verify. Documentation uses standard customer templates to speed approvals and inbound inspection.
- In-line checks plus final inspection prevent field failures and cut warranty events.
- QA packages include specifications confirmation and formatted test data for quick review.
- Ongoing trend analysis drive preventive maintenance and raise long-term reliability.
| Test | Purpose | Result |
|---|---|---|
| High-temperature | Material stability | Pass at target temperature |
| Salt-fog | Corrosion robustness | Qualified for outdoor use |
| Vibration | Mechanical robustness | Reduced field failures |
Cost Drivers and Pricing
Budget planning for a drop starts with fiber and jacket choices and is shaped by volume and customization.
Typical prices range broadly—from about $30–$1,000 per unit—based on fiber grade (G.652/G.657/OM2–OM4), jacket material, length, and structural design.
Material choices, fiber grade, jacket type, and structure
The primary cost drivers are fiber grade, sheath material, and the structural type chosen for deployment.
Self-supporting designs and steel members increase material/labor. Custom colors, logos, and print legends add setup and impact pricing on small runs.
Length/Volume/Customization Impact
Longer reels and higher volume orders reduce unit cost. Small quantities often carry setup fees and higher per-unit charges.
- Line changeovers and custom tooling increase lead time and add cost.
- Clear RFQs with schedule alignment let Shanghai Weiye OFC Equipment match quotes to delivery windows.
- Frameworks and indexed pricing stabilize budgets across phases.
| Factor | Effect on price | Recommendation |
|---|---|---|
| Optical grade | High impact | Balance spec vs. budget |
| Sheath material | Medium impact | Compare LSZH vs. PE for total cost |
| Order length / volume | Large | Consolidate where possible |
Lead times, MOQ, and delivery for the United States
Shanghai Weiye OFC Equipment keeps lead times/logistics clear so planners can align crews and sites. Predictable schedules reduce downtime and help control cost when a rollout is underway.
Typical production windows and capacity planning
Typical production windows run 4–5 days for orders under 100 km and 7–10 days for < 500 km. We plan capacity to track your milestones and to keep deliveries on time.
The service team issues production updates and tracking so installation teams can plan arrivals. For compressed schedules, we reserve contingency capacity to accelerate critical-path orders.
Why MOQ Matters
The MOQ is one kilometer. This reflects setup needs such as wire and jacket die adjustments that use startup material and generate scrap.
We review your put-ups and staging to choose reel sizes that cut waste and handling. Staggered batches can balance inventory with frequent, smaller deliveries to job sites.
Installation readiness and application scenarios
Site conditions dictate whether a self-supporting span, duct pull, or direct burial is the best fit for a project.
Deployment Considerations
For aerial runs, Shanghai Weiye OFC Equipment advises self-supporting designs with appropriate members to control sag and tension for long-term stability.
Duct installations work best with low-friction jackets and crush-resistant constructs so pulling does not damage fibers. PE jackets are typical for underground and buried paths where moisture resistance is needed.
Direct-buried designs require proper depth control per local codes and moisture barriers to protect the optic core over time.
Indoor riser/plenum distribution and ONT termination
Indoor riser/plenum routes prefer LSZH to meet smoke/flame codes. Flat drop cable forms strip clean and present controlled strength stubs for fast ONT terminations.
We advise on steel vs FRP (dielectric) strength members based on bonding needs, lightning risk, and hardware compatibility. Standardized line prep reduces install time and reduces scrap.
| Scenario | Key design | Field note |
|---|---|---|
| Aerial | Self-supporting (steel/FRP) | Check tension and messenger hardware |
| Underground duct | Low-friction jacket, crush resistance | Use pull tape + lubricant |
| Direct burial | PE with moisture barrier | Follow local depth and warning tape rules |
| Interior | LSZH jacket, tight bend support | Maintain bend radius at wall penetrations |
Our approach delivers a consistent installation across indoor outdoor transitions. That leads to fewer callbacks, faster activations, and reliable field performance for your system.
Comprehensive Support & After-Sales
Our team coordinates testing, scheduling, and installation guidance to avoid surprises in deployment.
Shanghai Weiye OFC Equipment offers engineering support from early requirements capture through approved drawings and pilot builds. We deliver documentation templates and clear installation notes so field crews share a unified plan.
After-sales service covers rapid response, root-cause analysis, and corrective actions. All products ship with full test reports and traceability to support QA acceptance.
- Round-the-clock availability for status updates and technical guidance.
- Warranty with free replacement if any quality problems are confirmed.
- Schedule coordination for expedites and urgent changes.
- Config control so shipped items match agreed requirements every time.
| Support area | What we do | Benefit |
|---|---|---|
| Engineering | Spec review & pre-production builds | Reduced field issues |
| Testing | Lab + 100% reports | Traceable quality |
| Service | Rapid replacement & root-cause | Lower downtime |
Wrap-Up
Select Shanghai Weiye OFC Equipment for custom drops, quick lead times, and full traceability.
We deliver customized FTTH drop solutions that combine materials with validated manufacturing and lab tests. Every reel includes a 100% test report and documented lab trials to support field acceptance in the United States.
A hardened production line, including CLX-BPO2-enabled prep machines, cuts variability and shortens turnaround. Our equipment set standardize strip and stub lengths so installers see consistent results at turn-up.
From fiber selection through jacket, printing, and packaging, we balance design and cost to maximize service life. Dedicated customer support guides scheduling, logistics, and after-sales care so your deployment remains on plan.
Get in touch with Shanghai Weiye OFC Equipment to align specifications, timeline, and volume. We stand behind every fiber optic and optic cable shipment with lab validation and responsive service.
